A modern, single-page note-taking app with real-time collaborative editing, built as a serverless application on AWS Lambda.

• Front-end: React web app using Apollo Client and Material UI
• Back-end: GraphQL API powered by Apollo Server, MongoDB (for data), and DynamoDB (for WebSocket subscription state)

• Real-time collaborative editing with operational transformation
• Per-user version history
• Full offline support with Progressive Web App (PWA) features
• Live presence and caret position tracking for collaborators
• Secure note sharing via unique links and QR codes
• Multi-account support, including a privacy-focused local-only account
• Drag-and-drop note organization
• Responsive, high-performance user interface
• Mobile-friendly design
• Dark mode
• Serverless, cost-efficient architecture using managed cloud services
• Infinite scroll with cursor-based pagination and auto-refresh for notes

Prerequisites:

• Docker (for local MongoDB and DynamoDB)
• Node.js (v22+ recommended)
• AWS CLI (optional, for deployment)

Development:

1. Install dependencies: npm install
2. Start development mode: npm run dev
3. Open http://localhost:5173 in your browser

I built this project to showcase my ability to develop robust, full-stack applications using modern web technologies and cloud-native architectures. Note-taking is a widely applicable use case that highlights core challenges of most web apps, including real-time sync and offline-first design. By leveraging managed cloud services like AWS Lambda, MongoDB, and DynamoDB, I aimed to build a scalable, serverless solution aligned with current industry demands.

Notes is designed to be always available and cost-effective by leveraging AWS Lambda and other managed services. MongoDB is used for its flexible schema and easy integration with AWS. The architecture supports real-time collaboration and sharing without the need for a dedicated server.

Architecture diagram:

• collab:
  Core collaborative editing logic, including operational transformation based on easysync-full-description.
• api:
  GraphQL API logic, MongoDB schemas, and DataLoader for efficient data fetching.
• lambda-graphql:
  Lambda handlers for GraphQL HTTP requests and WebSocket subscriptions. Subscription state is managed in DynamoDB.
  Based on Graphql Lambda Subscriptions.
• app:
  React front-end with account management, note sharing, and local notes.
• infra:
  AWS CDK code for deploying infrastructure as CloudFormation templates.
• api-dev-server:
  Local development server that adapts Lambda handlers for Express and WebSocket, enabling fast local development.

This project includes:

• Unit and integration tests (run with Vitest)
• End-to-end tests for the app (run with Cypress)

To run all tests locally:

1. Install dependencies: npm install
2. Build all packages: npm run ci:step:build
3. Start local databases (required for integration and end-to-end tests): npm run db:start
4. Run all tests: npm run test

To visually run Cypress end-to-end tests only:

1. Start local databases: npm run db:start
2. Build API for local usage: npm run -w dev-server build
3. Start test version of the API: npm run api:start:test
4. Build test version of the app: npm run -w app build:test
5. Start test version of the app: npm run app:start:test
6. Open Cypress UI: npm run cypress

Cypress end-to-end tests can also be run in headless mode:

npm run -w app test:e2e:run

To check code coverage:

Packages app and collab have coverage installed. Run them with package-specific commands, e.g. npm run -w collab coverage.

Tests are also run automatically on each pull request via GitHub Actions.

Prerequisites:

• Node.js (v22+)
• AWS CLI installed and configured (aws configure)

Steps:

1. Clone the repository and install dependencies:

   git clone https://github.com/knemerzitski/notes.git
   cd notes
   npm install

2. Create and fill .env.production.local with your production configuration.
   See .env.example for required variables.
3. Build the project:

   npm run ci:step:build

4. Deploy infrastructure with AWS CDK:

   npm run deploy

After deployment:

• The output will include the deployed app’s URL.
• Visit the URL to verify the deployment.

To remove the deployed stack:

(cd packages/infra && npx cdk destroy)

• React
• Material UI
• Vite
• PWA
• Apollo GraphQL
• WebSockets
• MongoDB
• DynamoDB
• AWS Lambda
• AWS CDK
• Docker
• GitHub Actions
• TypeScript
• Vitest

Notes is MIT licensed.
